Features

• Smart Cross-Beam UV

  The spiral quartz glass tube of Smart UV purifier has been protected with a powerful UV dosage ,freeing your water from contamination right from the time it passes through the nozzle till it flows down to the glass.

• Smart Flow

  The purifier with its advanced technology can now deliver upto 2 liters of water in just a minute. May it be filling up bottles to be carried outdoors or stocking up water at home, the Aquaflow DX would be the right choice to make.

• Voltage Stabilizer

  The in-built voltage stabiliser ensures that your purifier works flawlessly even during voltage fluctuations or low voltage.

• Warranty

  The goods are warranted against defects arising from faulty designs, workmanship and materials for 12 months from the date of installation or 15 months from the date of sale, whichever is earlier. T&C apply

Tech Specification

Physical Specifications

• DIMENSIONS MM (WxDxH)
  310 x 170 x 400
• Weight
  4.10 kgs
• Installation Type
  Table Top, Wall Mounting, Wall Mount / Table Top
• Storage Capacity
  No Storage

Technology

• Purification Modules
  Clarity Cartridge Chemi Block UV Chamber

Technical Specifications

• Recommended for
  Water supplied by Municipal Corporations sourced from lakes, rivers, etc and does not taste salty
• Applicable TDS Range
  1 - 200 mg / litre
• Water Flow Rate
  2 Litre / Minute
• Input Water Pressure
  2.0 kg / sq.cm0.4 kg / sq.cm
• Input Water Temperature
  10 - 40°C
• Input Water Chlorine (Max)
  0.2 mg / litre
• Input Water Iron
  0.3 mg / litre
• Input Water Turbidity (Max)
  15 NTU
• Life of UV Lamp
  5000 burning hours
• Operating Input Voltage
  230V AC / 50 Hz
• UV Lamp
  8 Watts

Power Specifications

• Power Consumption
  20 Watts

Bottle

Silicon Mouth Piecie

Cap

Technology

UV technology

This technology uses ultra violet rays to boil and purify the water. The water thus derived is safe and made free from all disease-causing micro organisms. The water treated by UV technology has all the benefits of boiling water for 20 minutes in less than a minute. Moreover it also rules out the possibility of recontamination, which always exists while cooling and handling, when boiling water manually.

UV technology treats water in 3 stages.

• First being filtration of suspended particles like dust, rust and mud up to 5 microns. In the next stage the technology enables itself to absorb organic impurities, foul smell & taste, lead, pesticides and VOCs.
• Later in the third and final stage, the ultra violet rays deactivate bacteria, virus, protozoa including cyst and other disease-causing micro organisms.
• The entire purification process is natural and free from chemicals and also retains the natural taste of water and all essential minerals required, making the water consumable.
